Product Details:

Get Best Price Contact Now

Detail Information
Highlight:

207-26-00200 swing motor gearbox

,

207-26-00201 swing motor gearbox

,

207-26-00200

Product Description

PRODUCT PARAMETERS
Part name PC300-7 PC350-7 PC360-7 Swing gearbox
Equipment Apply to KOMATSU EXCAVATOR
Part no. 207-26-00200  207-26-00201 207-26-00210
NO.1 sun gear spline teeth 18 splines
Swing pinion shaft teeth 13T
Item condition New
Logo LB
Gross weight 380 kg
MOQ 1 pc


Product Description

207-26-00200 207-26-00201 207-26-00210 Swing Motor Gearbox PC300-7 PC350-7 PC360-7 Komatsu SWING MACHINERY 0207-26-00200 207-26-00201 207-26-00210 Swing Motor Gearbox PC300-7 PC350-7 PC360-7 Komatsu SWING MACHINERY 1

Pos. Part No Qty Parts name Comments
    207-26-00201   [1]   SWING MACHINERY A. Komatsu 400 kg.
    ["SN: 40574-UP"] analogs:["2072600200"] |1.
   1.   207-26-71191   [1]   CASE Komatsu 153 kg.
    ["SN: 40574-UP"] analogs:["2072671190"]
   2.   07049-02430   [2]   PLUG Komatsu 0.003 kg.
    ["SN: 40003-UP"]
   3.   06000-22222   [1]   BEARING Komatsu OEM 7.452 kg.
    ["SN: 40574-UP"]
   4.   06000-22324   [1]   BEARING Komatsu OEM 24.602 kg.
    ["SN: 40574-UP"] analogs:["2072671320"]
   5.   207-26-62180   [1]   SHAFT Komatsu OEM 54 kg.
    ["SN: 40574-UP"] analogs:["2072671160"]
   6.   207-26-61210   [1]   SEAL Komatsu OEM 0.17 kg.
    ["SN: 40574-UP"]
   7.   207-26-54263   [1]   COVER Komatsu 1.13 kg.
    ["SN: 40574-UP"] analogs:["2072671280"]
   8.   01010-81040   [12]   BOLT Komatsu 0.288 kg.
    ["SN: 40574-UP"] analogs:["0101051040", "R0101081040"]
   9.   01643-31032   [12]   WASHER Komatsu 0.054 kg.
    ["SN: 40574-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
   10.   07000-15390   [1]   O-RING Komatsu OEM 0.05 kg.
    ["SN: 40001-UP"]
   11.   207-26-71581   [1]   CARRIER Komatsu OEM 20.86 kg.
    ["SN: 40574-UP"] analogs:["2072671580"]
   12.   207-26-71540   [4]   GEAR Komatsu 4.08 kg.
    ["SN: 40001-UP"]
   13.   206-26-71270   [4]   BEARING Komatsu 0.26 kg.
    ["SN: 40001-UP"]
   14.   20Y-27-21250   [8]   WASHER Komatsu China 0.03 kg.
    ["SN: 40001-UP"]
   15.   20Y-26-21320   [4]   PIN Komatsu China 1.33 kg.
    ["SN: 40001-UP"]
   16.   20Y-26-21330   [4]   PIN Komatsu China 0.1 kg.
    ["SN: 40001-UP"]
   17.   208-26-52230   [1]   PLATE Komatsu 1.22 kg.
    ["SN: 40001-UP"]
   18.   205-32-51211   [1]   BOLT Komatsu 0.17 kg.
    ["SN: 40001-UP"]
   19.   207-26-71551   [1]   RING GEAR Komatsu 42 kg.
    ["SN: 40574-UP"] analogs:["2072671550"]
   20.   01010-81645   [18]   BOLT Komatsu China 0.104 kg.
    ["SN: 40001-UP"] analogs:["0101061645", "801015187", "0101031645", "0101051645", "37A0911184", "801014184"]
   21.   01643-31645   [18]   WASHER Komatsu 0.072 kg.
    ["SN: 40001-UP"] analogs:["802170005", "0164301645"]
   22.   207-26-71530   [1]   GEAR Komatsu OEM 5.85 kg.
    ["SN: 40001-UP"]
   23.   207-26-71261   [1]   PLATE Komatsu OEM 0.15 kg.
    ["SN: 40001-UP"]
   24.   207-26-71570   [1]   CARRIER Komatsu OEM 6.53 kg.
    ["SN: 40001-UP"]
   25.   207-26-71520   [3]   GEAR Komatsu 2 kg.
    ["SN: 40001-UP"]
   26.   22U-26-21320   [3]   BEARING Komatsu 1.1 kg.
    ["SN: 40001-UP"]
   27.   22U-26-21240   [6]   WASHER Komatsu 0.6 kg.
    ["SN: 40001-UP"]
   28.   207-26-71210   [3]   PIN Komatsu 0.66 kg.
    ["SN: 40001-UP"]
   29.   04064-04018   [6]   RING Komatsu 0.001 kg.
    ["SN: 40001-UP"] analogs:["802250040"]
   30.   207-26-71250   [1]   HOLDER Komatsu 0.75 kg.
    ["SN: 40001-UP"]
   31.   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
    ["SN: 40001-UP"]
   32.   207-26-71510   [1]   GEAR Komatsu OEM 1.52 kg.
    ["SN: 40001-UP"]
   34.   207-26-71610   [1]   COVER Komatsu China
    ["SN: 40001-UP"]
   35.   01010-81240   [10]   BOLT Komatsu 0.052 kg.
    ["SN: 40001-UP"] analogs:["801015573", "0101051240"]
   36.   01643-31232   [10]   WASHER Komatsu 0.027 kg.
    ["SN: 40001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
   37.   07042-30617   [2]   PLUG Komatsu China
    ["SN: 40001-UP"]
   38.   07042-30108   [1]   PLUG Komatsu 0.008 kg.
    ["SN: 40001-UP"] analogs:["0704220108"]
