Product Details:

Get Best Price Contact Now

Detail Information
Highlight:

SK350-8 swing drive gearbox

,

swing drive gearbox LC32W00011F1

,

LC32W00011F1 swing reduction gearbox

Product Description

PRODUCT PARAMETERS
Part name SK350-8 swing gearbox
Equipment Apply to Kobelco EXCAVATOR
Part no. LC32W00011F1
NO.1 sun gear spline teeth 16 splines
Swing pinion shaft teeth 16T
Item condition New
Logo LB
Gross weight 400 KG
MOQ 1 pc


Product Descriptio

SK350-8 Swing Drive Gearbox LC32W00011F1 Swing Reduction Gearbox SK350-8 Swing Reducer 0SK350-8 Swing Drive Gearbox LC32W00011F1 Swing Reduction Gearbox SK350-8 Swing Reducer 1SK350-8 Swing Drive Gearbox LC32W00011F1 Swing Reduction Gearbox SK350-8 Swing Reducer 2

Pos. Part No Qty Parts name Comments
. . LC15V00027F2 [1]   HYDRAULIC MOTOR   SM Swing (Motor and Reduction)
. . LC32W00011F1 [1]   REDUCER   KOB Swing Reduction Assembly Includes Refs. 1-40
1. LC32W01027P1 [1]   PINION   KOB
2. LC32W01060P1 [1]   SHAFT   KOB
3. LC32W01006P1 [1]   SUN GEAR   KOB
4. LC32W01021P1 [3]   PINION   KOB
5. LC32W01017F1 [1]   SPIDER ASSY.   KOB
6. LC32W01019P1 [1]   SPIDER   KOB
7. LC32W01020P1 [3]   SHAFT   KOB
8. LC32W01008P1 [1]   SUN GEAR   KOB
9. LC32W01024P1 [4]   PINION   KOB
10. LC32W01009P1 [1]   RING GEAR   KOB
11. LC32W01023P1 [1]   SPIDER   KOB
12. LC32W01025P1 [4]   SHAFT   KOB
13. LC32W01036P1 [11]   NEEDLE BEARING   KOB
14. LC32W01030P1 [1]   SPHERICAL BEARING   KOB Spherical
15. LC32W01031P1 [1]   SPHERICAL BEARING   KOB Spherical
16. LC32W01032P1 [1]   OIL SEAL   KOB
17. LC32W01010P1 [1]   HOUSING   KOB
18. LC32W01033P1 [1]   OIL SEAL   KOB
19. LC32W01011P1 [1]   SLEEVE   KOB
20. LC32W01012P1 [1]   SLEEVE   KOB
21. LC32W01013P1 [1]   PLATE   KOB
22. LC32W01061P1 [1]   PLATE   SM
23. LC32W01014P1 [1]   RING   KOB
24. LC32W01022P1 [6]   WASHER, THRUST   KOB WASHER,THRUST
25. LC32W01026P1 [8]   WASHER, THRUST   KOB WASHER,THRUST
26. ZR16X04500 [1]   RING   KOB Snap
27. ZR16X04200 [3]   SNAP RING   KOB
28. ZP26D10040 [4]   ROLL PIN   KOB Spring
29. ZS23C20200 [12]   SCREW,Hex Socket Head, M20 x 200mm   KOB Cap
30. ZG91V02000 [1]   LUBE NIPPLE,67 Degree x 1/8" PT   KOB 67° x 1/8" PT Superseded by part number: 72283072
31. 2444Z3305 [1]   BREATHER   KOB Valve, Relief
32. YN32W01080D2 [1]   TUBE   KOB
33. ZG31U08000 [1]   HYD CONNECTOR   SM 90
34. ZE82T08000 [1]   PLUG   KOB
35. PV02B01073DE [2]   CAP   KOB
36. LC32W01062P1 [3]   SCREW   SM Cap
37. LC32W01018D1 [1]   SHIN   KOB (0.1)
38. LC32W01018D2 [1]   SHIN   KOB (0.2)
39. LC32W01018D3 [1]   SHIN   KOB (0.3)
40. LC32W01018D4 [1]   SHIN   KOB (0.5)
